Metal Processing Capabilities

Cutting Edge Processing Capabilities Available

At Sol's Pipe & Steel, LLC, we have excellent metal processing capabilities. You can have us stitch cut beams up to 40' long on CNC tables, or manually stitch cut up to 60' long - if you give us extra time. Contact us to learn more today.


FIRST-RATE PROCESSING CAPABILITES AVAILABLE

SAW CUTTING

  • Max beam size = 36"
  • Max pipe size = 24"


  • Max height for miter cutting = 14"
  • Max angle for miter cutting = 45 degrees
  • Closest tolerance within 1/16"


PLATE BURNING

Plasma thicknesses:

  • Carbon steel = gauge material through 1-1/2" plate


  • Stainless and alum = gauge material through 3" plate


Oxy-fuel burning

  • Carbon steel through 12" plate Standard cutting tolerance
  • 3" plate and under = +/- 1/16"
  • 3-1/4" through 6" = +/- 1/8"
  • 7" through 12" = +/- 1/4"

DRILLING

Holes up to 5" diameter and up to 12" deep in plate


Tolerance

  • Hole location within 1/16"
  • Hole diameter within .005"
